| Component Type | Details |
|---|---|
| CPU | Octa-core (4xCortex-A73, 2.0GHz & 4xCortex-A53, 2.0GHz) Helio P60, 12nm |
| AI Cores | 2 cores APU |
| Platform | MediaTek MT6771 |
| GPU | ARM Mali G72 MP3 800MHz |
| architecture | 64 bit |
| Memory | 4GB LPDDR4X RAM |
| Shipped Android Version | Android 9.0 Pie |
| Storage | 128 GB DDR4X (expandable storage up to 256GB (VFAT)) |
| Battery | 5150 mAh |
| Height | 156.9 mm |
| Width | 74.3 mm |
| Thickness | 8.8 mm |
| Weight | 186g |
| Display | 6.3" (16.002 cm) Waterdrop Advanced In-cell Display |
| Aspect Ratio | 19.5:9 |
| Screen Ratio | 92.7% |
| Screen resolution | 2340 x 1080 pixels, FHD+ |
| Pixel density | 409 PPI |
| Quick charging | Yes, 18W |
| Wifi | Yes, IEEE802.11 a/b/g/n, Supports 5G Wi-Fi Signal / Wi-Fi Direct / Wi-Fi Display |
| Bluetooth | v4.2, Bluetooth HID |
| USB type C | Yes |
| NFC | Yes, supports read/write, card emulation, and P2P |
| Network support | Both SIM slots are compatible with 4G, support 4G VoLTE in both slots simultaneously |
| GPRS | Available |
| EDGE | Available |
| SIM size | SIM1: Nano, SIM2: Nano (Hybrid) |
| Sensors | P/L-Sensors, Accelerometer, Gyroscope, Geomagnetic Sensor |
| Rear Dual Camera | Front Camera | Video |
|---|---|---|
| 16MP + 8MP | 16MP | 4K 30FPS |
| 6-element lens | 5-element lens | 1080P, 30fps |
| F/1.7 aperture | f/2.0 aperture | 720P, 30fps |
| 1.12 μm pixels | Selfie countdown | |
| 1/2.8" optical forma | Face recognition | |
| Dual LED flash | ||
| Face recognition | ||
| Real-time filters | ||
| HDR |
| Network | Bands |
|---|---|
| 2G | GSM 2 /3 /5 /8 |
| 2G | CDMA1X BC0,BC1 |
| 3G | EVDO BC0,BC1 |
| 3G | WCDMA 1 /2 /4 /5 /6 /8 /19 |
| 3G | TD-SCDMA 34 /39 |
| 4G | TDD-LTE 34 /38 /39 /40 /41 |
| 4G | FDD-LTE 1 /2 /3 /4 /5 /7 /8 /12 /13 /17 /18 /19 /20 /25 /26 /28A /28B |
This device tree can be used to build twrp for UMIDIGI F1 (fiona)
export ALLOW_MISSING_DEPENDENCIES=true
. build/envsetup.sh
lunch omni_fiona-eng
mka recoveryimage
